The EMT 140 plug-in gives you three separate plates, a damper that runs from 0.5 to 5.5 seconds, and one input filter shared across all of them. That last part trips people up. You cannot filter plate A one way and plate C another inside a single instance.
Wet solo is switched on by default, which is the right call on a send and the wrong one on an insert. Leave it on, and the mix knob stops mattering. Turn it off, and you get a blend control that runs on a logarithmic taper, with 12 o'clock landing at roughly 15 percent wet, not half.
So the first two decisions are made before you touch a single reverb parameter. Send or insert, and which plate. Everything after that is trimming.
Plate C runs modern Martech electronics on a recently serviced unit, and it reaches furthest across the frequency range. Reach for it when the mix is busy, and you need the tail to stay audible without pushing the send. A and B suit sparser arrangements where you want the reverb to sound a little older than the source.
The input filter changes shape depending on which electronics you picked. The EMT side gives you a cut at 80 Hz, at 4, 10 or 16 dB down. The Martech side gives you a shelf you can park at 90, 125, 180, 250, 270 or 360 Hz. You can afford several instances now, since the 140 losing its DSP requirement lifts the old ceiling on how many plates run at once.
Push the damper into the upper half of its range, add predelay that keeps a lead vocal readable, and the plate opens out rather than smears. Engineers have worked this way for decades. Alan Parsons has said the 140 was the only reverb used on Dark Side of the Moon. That is a lot of range from one plate.
Modulation is subtle by design. Rate runs from 0.01 to 1.0 Hz, and depth tops out at 10 cents. Even the maximum is a gentle drift rather than a chorus. A little depth stops a long tail sounding frozen.
One thing surprises people who have only used plate emulations. A well-maintained plate is smooth, not bright, and the 140 will not hand you air on its own. If you want top end, brighten the signal going in or lift the return with the plug-in's own shelving EQ. That EQ gives you plus or minus 12 dB. The low shelf places anywhere between 20 Hz and 2 kHz, and the high shelf between 200 Hz and 20 kHz.
Snare is where the 140 earns its keep, and the settings are short and narrow. Bring the damper down toward the bottom of its range and keep predelay modest. Use the width control to pull the tail in from full stereo when the snare needs to stay centered. Width runs from 0 to 100 percent, with 0 collapsing the return to mono.
Remember that the EQ carries the same restriction as the input filter. One per instance, applied to whichever plate is active. If you want a filtered plate C on vocals and an unfiltered plate A on snare, that is two instances. Not one with two presets.
The output meter is a vintage VU, so it responds slowly and will not show you fast peaks. Watch your channel meter for those. The power switch bypasses the plug-in without unloading it. That matters when you are comparing wet and dry versions of the same take across several passes.
Wet solo is switched on by default, which is the right call on a send and the wrong one on an insert. Leave it on, and the mix knob stops mattering. Turn it off, and you get a blend control that runs on a logarithmic taper, with 12 o'clock landing at roughly 15 percent wet, not half.
So the first two decisions are made before you touch a single reverb parameter. Send or insert, and which plate. Everything after that is trimming.
The three plates are not three flavors of one sound
Plates A and B model the original EMT electronics, and both were left deliberately untuned, which is why they sound slightly uneven across the spectrum. That unevenness is the point. It is what people are chasing when they say a plate has character.Plate C runs modern Martech electronics on a recently serviced unit, and it reaches furthest across the frequency range. Reach for it when the mix is busy, and you need the tail to stay audible without pushing the send. A and B suit sparser arrangements where you want the reverb to sound a little older than the source.
The input filter changes shape depending on which electronics you picked. The EMT side gives you a cut at 80 Hz, at 4, 10 or 16 dB down. The Martech side gives you a shelf you can park at 90, 125, 180, 250, 270 or 360 Hz. You can afford several instances now, since the 140 losing its DSP requirement lifts the old ceiling on how many plates run at once.
Predelay and damper time carry the vocal
Predelay runs from 0 to 250 milliseconds on a logarithmic scale, with noon sitting at 50 milliseconds. That is already a long way for most vocals. Small moves here do more than large moves on the damper, because predelay is what separates the dry word from the tail behind it.Push the damper into the upper half of its range, add predelay that keeps a lead vocal readable, and the plate opens out rather than smears. Engineers have worked this way for decades. Alan Parsons has said the 140 was the only reverb used on Dark Side of the Moon. That is a lot of range from one plate.
Modulation is subtle by design. Rate runs from 0.01 to 1.0 Hz, and depth tops out at 10 cents. Even the maximum is a gentle drift rather than a chorus. A little depth stops a long tail sounding frozen.
One thing surprises people who have only used plate emulations. A well-maintained plate is smooth, not bright, and the 140 will not hand you air on its own. If you want top end, brighten the signal going in or lift the return with the plug-in's own shelving EQ. That EQ gives you plus or minus 12 dB. The low shelf places anywhere between 20 Hz and 2 kHz, and the high shelf between 200 Hz and 20 kHz.
The input filter is what keeps drums out of the mud
Send kit pieces to the plate individually rather than routing the whole drum bus into it. Low frequencies pile up fast in a plate, and a kick going into a 3-second tail will bury everything you did to the low end. The bass cut exists for exactly this.Snare is where the 140 earns its keep, and the settings are short and narrow. Bring the damper down toward the bottom of its range and keep predelay modest. Use the width control to pull the tail in from full stereo when the snare needs to stay centered. Width runs from 0 to 100 percent, with 0 collapsing the return to mono.
Remember that the EQ carries the same restriction as the input filter. One per instance, applied to whichever plate is active. If you want a filtered plate C on vocals and an unfiltered plate A on snare, that is two instances. Not one with two presets.
The output meter is a vintage VU, so it responds slowly and will not show you fast peaks. Watch your channel meter for those. The power switch bypasses the plug-in without unloading it. That matters when you are comparing wet and dry versions of the same take across several passes.
